VENTILATION IN HARMONY WITH THE PATIENT
Sensitive, precise synchronization and continuous adaptation functions combine to provide the necessary ventilatory support, enable access to optimal spontaneous ventilation levels, facilitate the weaning process and protect the patient from serious side effects such as volotrauma or atelectasis.
INSPIRATORY SUPPORT – THE STANDARD FOR NEWBORNS
Pressure support (PS) provides automatic leak compensation and gives the child better control of his or her breathing cycle by synchronizing inspiration and expiration. Continuous and automatic leak compensation ensures optimal inspiratory times.
VOLUME GUARANTEE
The Volume Guarantee (VG) feature combines the advantages of pressure-controlled ventilation with those of volume-controlled ventilation. The preset tidal volume is maintained constant, regardless of spontaneous ventilation or changing lung conditions. The guaranteed volume ensures sufficient ventilation while avoiding the risk of volotrauma.
BABYFLOW NASAL CPAP
The Babylog® 8000 plus combines all the benefits of non-invasive ventilation with an easy-to-use nasal CPAP system designed specifically for smaller patients. The unique mask design provides stable, atraumatic CPAP ventilation.
HIGH FREQUENCY VENTILATION*
The Dräger Babylog® 8000 plus features a one-touch High Frequency Ventilation (HFV) option that can be used in conjunction with CPAP or VC modes. The ventilator accurately measures even the smallest tidal volumes, allowing you to fine-tune your therapy to your patients’ needs (*not available in the US).
SIMPLE OPERATION, ERGONOMIC DESIGN
A user-friendly, high-visibility display* shows your data in real time or as a graphical or numerical trend. The combination of user-customizable monitoring functions and intelligent alarms facilitates workflow and allows the caregiver to focus on patient care.
CONTROLS
• Control principle Continuous flow, pressure-limited, time-paced
• Conventional ventilation IMV/IPPV, CPAP
• Triggered ventilation IMV, SIPPV, PSV1), leak-adapted
• Flow/volume trigger, leak-adapted
• Trigger delay approx. 30 milliseconds
• High-frequency ventilation1) 3) CPAP+HFV, IMV+HFV
• Frequency 5 to 20 Hz
• Guaranteed volume ventilation1) SIMV+VG, SIPPV+VG, PSV+VG
• Loss of oxygen mixer (purge flow) 0 (zero) L/min
PARAMETERS
• Inspiratory oxygen concentration 21 -100 vol. % oxygen
• Peak inspiratory pressure 10 to 80 mbar
VPEP/CPAP 0 to 25 mbar
• Maximum rate 200 bpm2)
• Inspiratory time 0.1 to 2 seconds
• Expiratory time 0.2 to 30 seconds
• Inspiratory flow 1 to 30 L/min
• Basal flow (VIVE) 1 to 30 L/min
MONITORING
• Flow monitoring at Y-piece, integrated
• Volume monitoring at Y-piece, integrated
• Pulmonary function monitoring Compliance, C20/C resistance, time constant
• FiO2 monitoring integrated
• Real-time waveforms Flow and pressure, integrated
• Peak pressure at 99 mbar
• Mean airway pressure at 99 mbar
• Graphical trends 6 parameters, integrated
• Logbook of the last 100 alarms
