Product Description

Hartmann's Principle

New light path design, clear human eye imaging effffect

High-speed image acquisition system, advanced image processing and analysis

The screen can be rotated freely up and down

Automatic eye tracking for lifting, automatic measurement

Electric lifting amount tow

Offff-speed printer

Corneal apex distance: 0.0, 12.0, 13.75, 15.0

Spherical mirror degree: -20.00D ~ 20.00D (VD = 12mm, 0.01, 0.06, 0.12, 0.25 units)

Cylindrical power: 0.00D ~ 10.00D (0.06, 0.12, 0.25 units)

Axis position: 10 ~ 180 ° (1 ° unit)

Astigmatism symbol: -, , ±

Interpupillary distance: 10 ~ 86mm

Minimum pupil diameter: 2.0mm

Measurement completion time: <0.5 seconds.

Pupil diameter: 2.00-8.00mm

Measure light energy: <30uw (ensure measurement safety)

Cornea curvature radius: 5.0 ~ 10.0mm (0.01mm accuracy)

Cornea diopter: 33.00D ~ 67.0D (when the corneal equivalent diopter is 1.3375)

Corneal astigmatism: 0.00D-15.00D (0.06D / 0.12D / 0 25D units)

Stored data: 10 measurements each

Axis position: 1 ° ~ 180 °

Visual target: Guided cloud map

Display: 8-inch TFT touch screen (adjustable viewing angle)

Printer: 57mm thermal printer

Power supply: AC 100 ~ 250V, 50 / 60Hz, wide power supply

Net weight: 22 kg

Gross weight: 26.5 kg

Packing size: (length) 680mm x (width) 400mm x (height) 640mm

Leadtime within 7-30 days after payment received. Depends on availability of the product in the warehouse.
