Inspection range 90°

Inspection distance 30CM

Background light brightness White 31.5asb

Visual target brightness 1asb---10000asb

Visual target size GoldmannⅢ

Visual target interval time 200ms

Visual target interval time

Standard or adjustment according to patient reflection

Threshold test model

Center 5º-16,center10º-68,24-2,30-2,30º-60º,nasal step

Upper Threshold test model

30º-40 , 30º-76,P-60, 60º-81, 60º-120,1 90º-135 nasal side

Special detection strategy

Esterman monocular,Esterman binocular ,user-customized test,
150º driver monocular fast detection,150º driver monocular standard detection ,upper 36°detection,blind spot detection, 150ºhorizontal straightness detection

Pupil size test

Automatic

Fixation monitoring

Blind spot monitoring ,eye position eye position deviation alarm,eye deviation curve

Environment light detection

Automatic

Analysis software

Reliability analysis,single vision report,triple visionreport,GPA half vision analysis, GPA glaucoma developing analysis ,VFI vision index analysis

Operation system

Win7 above

Size 412mm(length)* 497mm(width)* 513mm(height)

Weight 17kg

Power 100-240V ,50-60Hz

Leadtime within 7-30 days after payment received. Depends on availability of the product in the warehouse.
