| Agitation Control & Range | Magnetic drive impeller (0 - 450 rpm) |
| Air | 0 - 3000 mL/min |
| Carbon Dioxide | 0 - 1500 mL/min |
| Dimensions (WXDXH) (mm) | 1038 x 1609 x 2122 |
| DO control | Single-use, optical 0 - 300% air saturation |
| Gas Connections | Male swagelock ¼ in. connector |
| Nitrogen | 0 - 1500 mL/min |
| Oxygen | 0 - 7000 mL/min |
| pH control | Single-use, optical 3 - 10(2) |
| Pumps | 5 x (perfusion in-out, base addition, sampling and inoculation), (7 if optional fill and drain pumps are ordered) |
| SCADA | Wonderware® |
| Temperature Control & Range | Double jacket – TCU 20 - 40 °C |
| Weight (kg) | 650 kg (without TCU) |
| Control | TMFC |
| Control Architecture | PLC |
