FEATURES
• Enhanced Guided Progression Analysis (GPA) software: Automatically identifies statistically significant progression Visual Field Index (VFI): New intuitive global index to determine the percentage of field loss
• Model Deviation Curves: Identifies local field loss, minimizing the effects of ocular media such as cataracts
• STATPAC: compares results to proprietary normative databases on age and glaucoma
• SITA-SWAP software for early detection: reduces blue-yellow threshold testing time to just 4 to 6 minutes
• Social Security Kinetic, Personalized, and Disability Testing offers a wide range of purpose-built testing protocols
• HFA-NET Pro with EasyConnect RCT: Provides plug-n-play connectivity solutions to improve practice efficiency
• Improved exam reliability: the patented system automatically tracks and aligns the position of the head and eyes
• DICOM Gateway option supports connectivity
• Touchscreen and menu-driven interface for easy use
• Ergonomic design for maximum comfort and versatility
• 40 GB hard drive storage
• Network capabilities
• Customizable Prints
SPECIFICATIONS
Test specifications
• Maximum time range (degrees): 89
• Stimulus duration: 200 ms
• Visual field test distance: 30 cm
• Background lighting: 31.5 ASB
Threshold Test Library
• 24-2, 30-2, 10-2, Macula
• 60-4, Nasal step
Threshold Testing Strategies
• SITA Standard, SITA Fast, Full Threshold, FastPac
• SITA-SWAP
Screening Test Library
• C40, C64, C76, C80, C-Armaly
• Peripheral test patterns
Screening test methods
• Age-corrected
• Threshold-related, Single Intensity
Specialized Test Library
• Social security disability, monocular, binocular
• Superior 36, 64
• Kinetic tests
• Personalized tests
Fixing control
• Blind Heijl/Krakau Spot Monitor
• Eye video monitor
• Eye tracking
• Head tracking
• Summit monitoring
• Remote eye video monitoring capability
Operator interface
• Touchscreen CRT with keyboard
Stimulus
• Frequency doubling
• White on white
• Red or blue on white
• Blue on yellow (SWAP)
General Test Features
• Stimulus sizes (Goldman IV)
• Foveal threshold test
• Automatic pupil measurement
User-defined test storage
Software Features
• Visual field index (VFI)
• EasyConnect RCT
• HFA-NET Pro
• Glaucoma Hemifield Test (GHT)
• DICOM Gateway Option
• Guided Progress Analysis (GPA)
• STATPAC 2 – Single Field Analysis
• Presentation of the series field
• Networking
Printer
• Printex thermal printer, table-mounted or external black and white laser printer
Data storage, retrieval and analysis
• Hard drive: 40 GB
• 3.5 floppy drive
• Magneto-optical disc player
Dimensions
• Height: 60 cm
• Width: 58 cm
• Depth: 51 cm
• Weight: 40 kg
