Lauda Variocool VC2000 circulation chiller
Features
Process thermostat for use with non-flammable temperature control media
Operation via cursor and softkeys
Powerful pressure pump
Can be upgraded with an interface module (analog module, contact module, RS 232/485 module, Profibus module, Ethernet-USB module)
Filling opening at the top, drain tap at the rear
Condenser cooling water
Color TFT display for simultaneous display of actual and setpoint values as well as graphical representation of the temperature curve
Fully electronic continuous controller with PID behavior
USB interface as standard
Integrated programmer with max. 150 segments, divisible into 5 programs
SmartCool system for energy-saving digital cooling control including automatic compressor control
Operation with non-flammable liquids (water, water/glycol)
Plain text menu navigation, six selectable languages: DE, EN, FR, ES, IT, RU
Electronic level indicator and low level alarm
Remote indication of fault via built-in neutral contact
Adjustable bypass for pressure limitation
Operation with non-flammable refrigerant (HFC), compliant with the F-Gas Regulation (EU) 573/2024
Technical features (according to DIN 12876)
Working temperature range: -20 ... 80 °C
Ambient temperature range: 5 ... 40 °C
Temperature stability: 0.05 ± K
Heating output max.: 2.25 kW
Maximum power consumption: 3.3 kW
Power consumption: 14 A
Maximum delivery pressure: 3.2 bar
Pump flow rate max. (pressure): 37 L/min
In / Outlet connection thread (outside): G 3/4
Pressure setting: Bypass
Maximum filling volume: 15 L
Water cooling connection thread (outside): 3/4 ″
Recommended cooling water temperature: 15 °C
Cooling water consumption: 5 L/min
Cooling water pressure difference min.: 1 bar
Maximum_Pressure_Cooling_Water: 10 bar
Dimensions (WxDxH): 450 x 550 x 790 mm
Weight: 64 kg
Mains supply: 230 V; 50 Hz
Power plug: Power cable with angled Schuko plug (CEE7/7)
