98639 KNF Dosierpumpe SIMDOS® 02 FEM1.02FT.18S PTFE

Chemical-resistant diaphragm metering pump SIMDOS® 02 FT.18 S - Delivery rate of 0.03 - 20 ml / min / pressure head 60 mWS, suction height 2 mWS - Pump head in material version PTFE diaphragm made of PTFE, valves made of FFKM - Manual delivery (Version S ) - Additional safety diaphragm for maximum protection - Easy to change the diaphragm by activating the maintenance command stored in the operating program Technical data Application Dosing of liquids Capacity (ml / min) for water at 20 ° C at head height zero 0.03 - 20 head pressure (mWS) 60 Suction head (mWS) 2 Hose connection (mm) ID1,6 / AD3,2 Permitted media and ambient temperature Ambient temperature +5 ... +40 ° C Media temperature +5 ... +80 ° C Weight (kg) 0,9 Dimensions W x H x D (mm) 93 x 144 x150 Material Pump head PTFE Diaphragm PTFE Valves FFKM Accessories Tripod holder Order no. 160474 Wall bracket Order no. 160473 Foot rest for RC version (RC = manual operation and external control) Order no. 155872 In-line filter FS 60 T PVDF mesh size 70 µm Order no. 165210 FS 60 X PEEK mesh size 35 µm Order no. 165212 Accessories (optional): Hose (PTFE material): 069684 Fitting for hose 1,6x3,2mm: 150213 Pressure retaining valve JFDV30FTZ: 166288
